SunSynk SYNK-5K-SG03LP1 - Three-Phase Parallel Inverter

SINGLE PHASE HI 3.6/5kW | Installer Manual30
Three-Phase Parallel Inverter
ON
1 2
ON
1 2
ON
1 2
Ground
L wireCAN N wire PE wire
Battery Pack
Grid
CAN/RS 485
L1 N PE L2 L3
LoadGEN Grid LoadGEN Grid LoadGEN Grid
A Phase Inverter No.1(master) B Phase Inverter No.2(master) C Phase Inverter No.3(master)
Backup Load
A Phase Master inverter B Phase Master inverter C Phase Master inverter
Home load
L3 L2 L1
N-BAR E-BAR
� AC Breaker
� AC Breaker
� AC Breaker
��� DC Breaker for battery
� DC Breaker
� DC Breaker
� DC Breaker
CT1
CT2 CT3
SYNK-3.6K-SG03LP1: 150A DC breaker SYNK-5K-SG03LP1: 150A DC breaker
� AC Breaker for grid port
SYNK-3.6K-SG03LP1: 40A AC breaker SYNK-5K-SG03LP1: 40A AC breaker
� AC Breaker for backup load
SYNK-3.6K-SG03LP1: 40A AC breaker SYNK-5K-SG03LP1: 40A AC breaker
� AC Breaker
Depends on Homeload
CT
Arrow pointing
to inverter
RS 485/ METER
parallel_1parallel_2
BMS 485/ CAN
DRMs
01 02 03
