SINGLE PHASE HI 3.6/5kW | Installer Manual6
PRODUCT INTRODUCTION
This multifunctional inverter combines the functions of an inverter, solar charger and battery charger to oer
uninterruptible power support with a portable size. Its comprehensive LCD display oers user-congurable
and easily accessible button operations such as battery charging, AC/solar charging, and acceptable input
voltage based on dierent applications.
Product Overview
1. Inverter Indicators 7. DRMs Port 13. Power On/O Button
2. LCD Display 8. Parallel Port 14. DC Switch
3. Function Buttons 9. Function Port 15. PV Input with Two MPPT
4. Battery Input Connectors 10. Generator Input 16. Battery
5. RS485/Meter Port 11. Load 17. Temperature Sensor
6. BMS 485/CAN Port 12. Grid 18. Wi-Fi Interface
��
1 2
1
2
5
9
10
11
12
7
6
3
4
8
13
14
15
16
17
18
