OPERATION & MAINTENANCE MANUAL SWE215F
(21) Emergency Exit Label
When accidents happen, and operator is trapped in cab,
operator can use life hammer located on the side of cab to
destroy window labeled with exit mark to get out of the
machine.
The safety structure being damaged is beyond repair. But
you could have it replaced with a new one.
Caution
Pay attention to the flying pieces while breaking out
emergency exit way. For better protection of your
safety, please keep sufficient distance from exit way
being damaged.
Exit hole must be big enough for operator to get out.
Make sure your safety.
(22) Center of Gravity Label
(23) Track Tension Adjustment Label
Pay attention to avoid being hurt by the fly-out of grease
nozzle while adjusting track tension.
The manual should be read carefully prior to adjust track
tension.
