OPERATION & MAINTENANCE MANUAL SWE215F
3.2 CONTROL DEVICE INSTRUCTIONS
3.2.1 Control Device Illustration
1- Throttle control knob 2-Starting switch 3-Work light switch
4-Wiper switch 5-Washer switch 6- Manual/Auto selection switch
7-Quick-change lock switch 8-Engine regeneration switch 9- A/C control panel
10-radio 11-Pilot safety lever
12- Left pilot control handle (one-key for idle speed)
13- Right pilot control handle (W/ horn switch)
14- Travel control lever 15- Monitor 16- Cigar lighter
