8.3 HYDRAULIC COMPONENT LIST
No.
Name
No
.
Name
1
diesel engine
16
bucket cylinder
2
plunger pump unit
17
boom cylinder
3
pilot oil source block
18
Travel motor
4
pilot safety solenoid valve
19
dozer blade cylinder
5
pilot two-speed solenoid valve
20
center rotation joint
6
pilot filter cooler
21
swing motor
7
main valve
22
arm cylinder
8
Bulldozing hand shank
23
boom swing cylinder
9
left foot value（crushed auxiliary
control）
24
Quick-changing splicer
10
Left joystick (pilot control
valve)——arm+swing
25
selector
valve——swing+quick
change switch
11
right joystick (pilot control
valve)——boom+bucket
26
oil return one-way valve
12
Travel foot value
27
oil cooler
13
right foot value（blade control）
28
oil return filter
14
Pilot oil catcher
29
air filter——breather
15
Auxiliarystop valve
