SUNWARD SWE80B - SWE60 UF Technical Specification

124
6.2 SWE60B TECHNICAL SPECIFICATION
6.2.1 Machine Specification
Machine specification
SWE60B
Operating weight
Equipped with
rubber track
6110 kg
Equipped with
steel track
6180 kg
Standard bucket capacity
0.18 m3
Track shoe width
400 mm
Power plant
Engine model
4TNV94L-BVSU
Type
Direct injection, water cooled, 4 strokes
Number of cylinders
4
Displacement
3.054 L
Rated power/revs
36.2 kW/2100 rpm
Fuel tank capacity
113 L
Hydraulic system
Main pump
2 variable plunger pump,1 gear pump
Flow capacity
2×59+42 L/min
Work pressure setting
24/24/21 MPa
Front work attchment
24 Mpa
Travel
24 Mpa
Slewing
21 Mpa
Pilot pressure setting
3.9 Mpa
Hydraulic oil tank capacity
96 L
Performance specification
Slewing speed
9.4 rpm
Travel speed
4.74/2.75 km/h
Max traction
42 kN
Max grade ability
35°
Bucket max digging force
47 kN
Arm max digging force
31 kN
Boom deflection angle
R48°/L72°
