SUNWARD SWE80B - SWE90 UF Technical Specification

166
6.8 SWE80F TECHNICAL SPECIFICATION
6.8.1 Machine Specification
Machine Model
SWE80F
Operating
weight
Equipped with
rubber track
7810 kg
Equipped with
steel track
7860 kg
Standard bucket capacity
0.28 m3
Track shoe width
450 mm
Power plant
Engine model
4TNV98C-SSU
Type
Direct injection, water cooled, 4 strokes
Number of cylinders
4
Displacement
3.319 L
Rated power/revs
46.2 kW/2200 rpm
Fuel tank capacity
118 L
Hydraulic system
Main pump
1 variable plunger pump
Flow capacity
162 L/min
Work pressure setting
26 MPa
Front work attachment
(reinforcement)FF
26 Mpa
Travel
26 Mpa
Slewing
26 Mpa
pilot pressure setting
3.9 Mpa
Hydraulic oil tank capacity
96 L
Performance specification
Slewing speed
10 rpm
Travel speed
4.0/2.4 km/h
Max traction
62 kN
Max grade ability
35°
Bucket max digging force
53 kN
Arm max digging force
36 kN
Angle of boom deflection
R73°/L60°
