2.2.1 METER FUNCTIONS
1. Simulative/numerical oil level
2. Simulative/numerical water temperature
3. Numerical rev
4. Numerical voltage
5. Working hours
6. Preheat indication
7. Fault record
8. Low oil pressure alarm
9. Low oil level alarm
10. Water overheat alarm
11.Air filter clogging alarm
12. Oil filter clogging alarm
13. GPS communication
14. Charging alarm
2.2.2 DISPLAY RANGE AND ALARM STATEMENT
1. Water temperature meter: Displayed by finger and numerical. If water temperature over than pre-set,
corresponding label will displayed in warning labels area; 2 seconds later, the red indicator light lights on and
the buzzer activated. This fault will be recorded.
2. Fuel meter: Displayed by finger and numerical. If fuel level lower than warning level, corresponding label
will displayed in warning labels area; 10 seconds later, the red indicator light lights on and the buzzer activated.
This fault will be recorded.
3. Working hours: Displays 6 digits (includes 1 digit behind radix point), displays 99999.9 hours at most;
when the machine is working (rotating speed fast than 200r/min or oil pressure over 0.1 Mpa), the meter
begins to count.
4. Voltage: Displayed numerically. Display the real value of voltage.
5. Rotating speed meter: Displayed numerically. Display range form 0 to 9999r/min. Number of tooth is
optional from 0 to 999.99.
6. Air filter: When air filter jam-up alarm switch earths, 5 seconds later, corresponding label will displayed in
warning labels area; the red indicator light lights on and the buzzer activated.
7. Oil filter: When oil filter jam-up alarm switch earths, 5 seconds later, corresponding label will displayed in
warning labels area; the red indicator light lights on and the buzzer activated.
8. Charging indication: When generator stopped, corresponding label and description will be displayed in
monitor.
9. Pre-heat indication: Input 12V power supply, the indicator lights on. And description will be displayed.
