6.7.5 Electrical Elements Table
NO.
NAME
NO.
NAME
1
Throttle servo-motor
27
Ignition lock
2
Safety relay
28
Monitor meter
3
Flameout control relay
29
Warm up relay
4
Fuel valve relay
30
Controller
5
Starter
31
Electric oil pump
6
Head light relay
32
Radio
7
generator
33
Washer assy.
8
Water temperature sensor
34
Wiper controller
9
Air filter indicator
35
Horn
10
Overheat warning switch
36
Lighter
11
Engine oil pressure warning switch
37
GPS
12
Solenoid power switch
38
Electric control case assy.
13
Throttle dail plate
39
Connector
14
Work light
40
Single core plug
15
Oil level sensor
41
1S Delayed module
16
Micro-active switch
42
15S Delayed module
17
Press button switch end mounting
frame
43
Standby relay 1
18
Press button switch mid-frame
44
Standby relay 2
19
Auto-idle switch
45
Standby relay 3
20
Quick selection switch
46
Horn relay
21
Front light switch
47
Fuel gasoline pump
22
Work light switch
48
18 Core junctor
23
Alarm light switch
49
22 Core junctor
24
Wiper switch
50
Warning lamp
25
Washer switch
51
Accumulator100Ah
26
Rocker switch cover
52
Battery clamp（with protective）
