6.9 SWE90UF TECHNICAL SPECIFICATION
6.9.1 Machine Specification
Machine model
SWE90UF
Operating
weight
Equipped with
rubber track
8160 kg
Equipped with
steel track
8340 kg
Standard bucket capacity
0.28 m³
Track shoe width
450 mm
Power plant
Engine model
4TNV98C
Type
Direct injection, water cooled, 4
strokes
Cylinder number
4
Displacement
3.319 L
Rated power/revs
46.2 kW/2200 rpm
Fuel tank capacity
120 L
Hydraulic system
Main pump
1 variable plunger pump
Flow
160 L/min
Work pressure
30 MPa
Front work
attachment(reinforcement)
30 Mpa
Travel
30 Mpa
Slewing
24.5 Mpa
Pilot pressure
3.5 Mpa
Hydraulic oil tank capacity
100 L
Performance specification
Slewing speed
11 rpm
Travel speed
4.5/2.7 km/h
Max traction
66.8 kN
Max grade ability
35°
Bucket max digging force
63.5 kN
Arm max digging force
37.5 kN
