33
The oil level of dipstick should be on the range of ―MIN‖ and ―MAX‖ mark (As figure 3.3.2).If oil level is too
low, please screw oil filling lip (2) to fill oil.
The way of using and maintenance engine please refer to “Diesel engine oil maintenance and usage
manual”.
Electrical device
Check all switch, all light indicator, safety warning device, battery electrolyte acidity, and fuses.
Air filter
When the indicator light on the meter flickers, which means the inhaling resistance reaching the maximum
value, the filter element shoule be maintained or replaced.
Oil level in hydraulic oil tank
Hydraulic oil filling label(As figure 3.3.3)：
【Important】Following notes for adding oil to hydraulic oil tank (As figure 3.3.5):
(1) Place machine on horizontal ground and retract all hydraulic cylinders,
the oil level doesn‘t allow it to exceed MAX mark.
(2) Similarly, when all hydraulic cylinders extend, the oil level should be
not lower than the MIN mark.
(3) It should choose recommended oil according to the Lubricant List.
(4) All filled hydraulic oil must pass through returning oil filter.
Engine staring and stopping label (As figure 3.3.7)：
