40
4.12 Initial Check-out
After the sensor box is secured and all the cables are connected, the system can be tested for operation.
1. Ensure the power cables for the sensor box are plugged into a suitable power source.
2. Turn console key switch ON to power ON to the sensor box.
• Notice that a small green light in the upper right corner on the front of the sensor box illuminates.
NOTE: The white power button on the sensor box is disabled; do not use it.
3. Turn the computer ON and start the WinDyn and NetDyn programs from desktop.
Prior to rst using the dynamometer, SuperFlow
recommends calibrating the systems torque
measurement sensor. Refer to "Calibrating the
Sensors" on page 63 in Chapter 6.
IMPORTANT
The system is now ready for use. Proceed to Chapter 5 for operation instructions. Consult the WinDyn
Operators Manual for detailed information on how to use the software.
NOTE: Refer to Chapter 6 for instructions on calibrating the various sensors in the system. If you
experience any problems in getting the system operational, or if the system fails to communicate
with the console or with WinDyn, contact SuperFlow Customer Service for assistance.
Sensor calibration is a critical function of accurate
measurements. Do not attempt to calibrate any
of the sensors in a SuperFlow Data Acquisition
System without the proper calibration equipment.
IMPORTANT
4.0 Installation
