45
8. Once docked and secured, you may lower the rear support post and remove it if you wish.
Dyno Shaft Connection
Figure 5.2 Driveshaft
The dynamometer shaft (gure 5.2) is driven by the engine in the same manner that a standard shift
transmission connects to the engine.
First install an adapter plate to the ywheel or ex plate. Engine Adapter Plates for many engines are
available from SuperFlow.
It is very important that the adapter plate be perfectly centered on the ywheel to minimize vibration and
damage to the engine and absorber.
Figure 5.3 Engine Connected
5.0 Operation
