Appendix D: BPN-SAS3-743A Backplane Specications
73
Rear Jumpers and Pin Denitions
The jumpers are used for internal texting only.
Explanation of Jumpers
To modify the operation of the backplane, jumpers
can be used to choose between optional settings.
Jumpers create shorts between two pins to
change the function of the connector. Pin 1 is
identied with a square solder pad on the printed
circuit board.
Note: On two pin jumpers, "Closed" means the
jumper is on and "Open" means the jumper is off
the pins.
Connector
Pins
Jumper
Setting
3 2 1
3 2 1
Figure D-2. Rear Jumpers
JP8
ACTLED
JP9
Jumper Settings
Jumper Jumper Settings Note
JP8 2-3: Default This is used for internal testing only.
JP9 1-2: Default This is used for internal testing only.
ACTLED Open: Default This is used for internal testing only.
