Chapter 1: Introduction
1-7
• Chassis intrusion detection
• System resource alert via Supero Doctor III
ACPI Features
• Slow blinking LED for suspend state indicator
• Main switch override mechanism
• ACPI Power Management
• Keyboard Wakeup from Soft-off
Onboard I/O
• Intel ICH10R supports six SATA ports (with support of RAID0, RAID1, RAID10,
RAID5 in the Windows OS Environment, and RAID 0, RAID 1, RAID 10 for the
Linux OS)
• Intel 82576 dual-channel Gigabit Ethernet controller supports dual Giga-bit
LAN ports (LAN 1/LAN 2)
• A PHY chip supports an IPMI_Dedicated LAN on the X8DTU-F
• One VGA Port supported by the Winbond WPCM450 BMC Controller
• Two COM ports(1 header, 1 port)
• PS/2 mouse and PS/2 keyboard ports
• Up to eight USB 2.0 (Universal Serial Bus) (2 Rear Ports, 2 Front Headers,
and 2 Type A Headers)
• Super I/O: Winbond W83527HG
• IPMI 1.5/2.0 with full KVM support (X8DTU-F only)
Note: IPMI 1.5/2.0 is supported by the X8DTU-F. For more information on
IPMI conguration, refer to the Embedded BMC IPMI User Guide @http://
www.supermicro.com/support/manuals/.
Other
• Console redirection
• Onboard Fan Speed Control by Thermal Management via BIOS
CD/Diskette Utilities
• BIOS ash upgrade utility and device drivers
Dimensions
• Proprietary 13.05" (L) x 12.075" (W) (331.47 mm x 306.71 mm)
