Supermicro X11DPG-QT User Manual

Super X11DPG-QT User Manual
182
Appendix D
UEFI BIOS Recovery
Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing
the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro
be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS
update. If you need to update the BIOS, do not shut down or reset the system while the BIOS
is updating to avoid possible boot failure.
D.1 Overview
The Unied Extensible Firmware Interface (UEFI) provides a software-based interface
between the operating system and the platform rmware in the pre-boot environment. The
UEFI specication supports an architecture-independent mechanism that will allow the UEFI
OS loader stored in an external storage device to boot the system. The UEFI o󰀨ers clean,
hands-o󰀨 management to a computer during system boot.
D.2 Recovering the UEFI BIOS Image
A UEFI BIOS ash chip consists of a recovery BIOS block and a main BIOS block (a main
BIOS image). The recovery block contains critical BIOS codes, including memory detection
and recovery codes for the user to ash a healthy BIOS image if the original main BIOS image
is corrupted. When the system power is turned on, the recovery block codes execute rst.
Once this process is complete, the main BIOS code will continue with system initialization
and the remaining POST (Power-On Self-Test) routines.
Note 1: Follow the BIOS recovery instructions in Section D.3 for BIOS recovery when
the main BIOS block crashes.
Note 2: If the recovery instructions in Section D.3 for BIOS recovery fail, you may use
the Supermicro Update Manager (SUM) Out-of-Band (OOB) (https://www.supermicro.
com.tw/products/nfo/SMS_SUM.cfm) to reash the BIOS.
Note 3: If the recovery block processes stated in Note 1 and Note 2 above fail, you will
need to follow the procedures to make a Returned Merchandise Authorization (RMA)
request. Refer to Section 3.5 for more information about the RMA request.

Supermicro X11DPG-QT Specifications

General

PS/2 ports quantity	0
IPMI LAN (RJ-45) port	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Number of SATA III connectors	10
Number of DIMM slots	16
Maximum LRDIMM memory	2000 GB
Supported RDIMM module capacity	64GB
Memory voltage	1.2 V
Supported memory types	DDR4-SDRAM
Supported memory clock speeds	2133, 2400, 2666 MHz
BIOS type	AMI
ACPI version	4.0
BIOS memory size	64 Mbit
RAID levels	0, 1, 5, 10
Wi-Fi	No
LAN controller	Intel® X550
Ethernet interface type	10 Gigabit Ethernet
On-board graphics card model	Aspeed AST2500
Bundled software	Intel Node Manager, IPMI2.0, KVM LAN, NMI, SPM, SSM, SUM, SuperDoctor 5, Watchdog
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 90 %
Supported QPI	10.4 GT/s
Processor socket	LGA 3647 (Socket P)
Processor manufacturer	Intel
Processor number of cores supported	28
Component for	Server
Motherboard chipset	Intel® C621
Audio output channels	7.1 channels
PCI Express x16 (Gen 3.x) slots	6

Weight and Dimensions

Depth	335.3 mm
Width	384 mm
