Supermicro X11DPG-QT User Manual

35
Chapter 2: Installation
DDR4 Memory Support for Intel Xeon Scalable-SP Processors
DDR4 Memory Support
Type
Ranks Per
DIMM & Data
Width
DIMM Capacity (GB)
Speed (MT/s); Voltage (V); Slots Per Channel (SPC) and DIMMs Per Channel
(DPC)
1 Slot Per Channel 2 Slots Per Channel
DRAM Density
1DPC (1-DIMM
Per Channel)
1DPC (1-DIMM Per
Channel)
2DPC (2-DIMM Per
Channel)
4Gb* 8Gb 1.2 V 1.2 V 1.2 V
RDIMM SRx4 4GB 8GB 2666 2666 2666
RDIMM SRx8 8GB 16GB 2666 2666 2666
RDIMM DRx8 8GB 16GB 2666 2666 2666
RDIMM DRx4 16GB 32GB 2666 2666 2666
RDIMM 3Ds QRX4 N/A 2H-64GB 2666 2666 2666
RDIMM 3Ds 8RX4 N/A 4H-128GB 2666 2666 2666
LRDIMM QRx4 32GB 64GB 2666 2666 2666
LRDIMM 3Ds QRX4 N/A 2H-64GB 2666 2666 2666
LRDIMM 3Ds 8Rx4 N/A 4H-128GB 2666 2666 2666
DDR4 Memory Support
Type
Ranks
Per DIMM
&
Data Width
DIMM Capacity (GB)
Speed (MT/s); Voltage (V); Slots Per Channel (SPC) and DIMMs Per Chan-
nel (DPC)
1 Slot Per Channel 2 Slots Per Channel
DRAM Density
1DPC (1-DIMM
Per Channel)
1DPC (1-DIMM
Per Channel)
2DPC (2-DIMM
Per Channel)
4Gb* 8Gb 16Gb 1.2 V 1.2 V 1.2 V
RDIMM SRx4 4GB 8GB 16GB 2933 2933 2933
RDIMM SRx8 8GB 16GB 32GB 2933 2933 2933
RDIMM DRx8 8GB 16GB 32GB 2933 2933 2933
RDIMM DRx4 16GB 32GB 64GB 2933 2933 2933
RDIMM 3Ds QRX4 N/A 2H-64GB 2H-128GB 2933 2933 2933
RDIMM 3Ds 8RX4 N/A 4H-128GB 4H-256GB 2933 2933 2933
LRDIMM QRx4 32GB 64GB 128GB 2933 2933 2933
LRDIMM 3Ds QRX4 N/A 2H-64GB 2H-128GB 2933 2933 2933
LRDIMM 3Ds 8Rx4 N/A 4H-128GB 4H-256GB 2933 2933 2933
DDR4 Memory Support for 2nd Gen Intel Xeon Scalable-SP
Processors
Notes: 1. 2933 MHz memory support in two-DIMMs per-channel (2DPC) conguration
can be achieved by using memory purchased from Supermicro. 2. Support for 2933
MHz memory is dependent on the CPU SKU. 3. 16Gb-based memory modules are
supported by 2nd Gen Intel Xeon Scalable-SP processors only.

Supermicro X11DPG-QT Specifications

General

PS/2 ports quantity	0
IPMI LAN (RJ-45) port	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Number of SATA III connectors	10
Number of DIMM slots	16
Maximum LRDIMM memory	2000 GB
Supported RDIMM module capacity	64GB
Memory voltage	1.2 V
Supported memory types	DDR4-SDRAM
Supported memory clock speeds	2133, 2400, 2666 MHz
BIOS type	AMI
ACPI version	4.0
BIOS memory size	64 Mbit
RAID levels	0, 1, 5, 10
Wi-Fi	No
LAN controller	Intel® X550
Ethernet interface type	10 Gigabit Ethernet
On-board graphics card model	Aspeed AST2500
Bundled software	Intel Node Manager, IPMI2.0, KVM LAN, NMI, SPM, SSM, SUM, SuperDoctor 5, Watchdog
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 90 %
Supported QPI	10.4 GT/s
Processor socket	LGA 3647 (Socket P)
Processor manufacturer	Intel
Processor number of cores supported	28
Component for	Server
Motherboard chipset	Intel® C621
Audio output channels	7.1 channels
PCI Express x16 (Gen 3.x) slots	6

Weight and Dimensions

Depth	335.3 mm
Width	384 mm
