Supermicro X11DPG-QT User Manual

19
Chapter 1: Introduction
1.2 Processor and Chipset Overview
Built upon the functionality and capability of the Intel Xeon Scalable-SP series or 2nd Gen
Intel Xeon Scalable-SP series processors (Socket P) and the Intel C621 chipset, the X11DPG-
QT motherboard provides system performance, power e󰀩ciency, and feature sets to address
the needs of next-generation computer users. This motherboard is ideal for general purpose,
cloud computing, and is optimized for server platforms used in data centers.
The Intel C621 chipset provides Enterprise SMbus support and includes the following features:
• DDR4 288-pin memory support on Socket P
• Support for MCTP Protocol
• Support for Management Engine (ME)
• Support of SMBus speeds of up to 400KHz for BMC connectivity
• Improved I/O capabilities to high-storage-capacity congurations
• SPI enhancements
• Intel Node Manager 4.0 for advanced power monitoring, capping, and management for
BMC enhancement
• The BMC supports remote management, virtualization, and the security package for en-
terprise platforms
Note: Node Manager 4.0 support is dependent on the power supply used in the system.
Features Supported by Intel Xeon Scalable-SP Processors
Intel Xeon Scalable-SP processors support the following features:
• Intel AVX-512 instruction support to handle complex workloads
• 1.5x memory bandwidth increased to 6 channels
• Hot plug and enclosure management with Intel Volume Management Device (Intel VMD)
• Rich set of available IOs with increased PCI-E lanes (48 lanes)
• Integrated Intel Ethernet Connection X722 with iWARP RDMA

Supermicro X11DPG-QT Specifications

General

PS/2 ports quantity	0
IPMI LAN (RJ-45) port	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Number of SATA III connectors	10
Number of DIMM slots	16
Maximum LRDIMM memory	2000 GB
Supported RDIMM module capacity	64GB
Memory voltage	1.2 V
Supported memory types	DDR4-SDRAM
Supported memory clock speeds	2133, 2400, 2666 MHz
BIOS type	AMI
ACPI version	4.0
BIOS memory size	64 Mbit
RAID levels	0, 1, 5, 10
Wi-Fi	No
LAN controller	Intel® X550
Ethernet interface type	10 Gigabit Ethernet
On-board graphics card model	Aspeed AST2500
Bundled software	Intel Node Manager, IPMI2.0, KVM LAN, NMI, SPM, SSM, SUM, SuperDoctor 5, Watchdog
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 90 %
Supported QPI	10.4 GT/s
Processor socket	LGA 3647 (Socket P)
Processor manufacturer	Intel
Processor number of cores supported	28
Component for	Server
Motherboard chipset	Intel® C621
Audio output channels	7.1 channels
PCI Express x16 (Gen 3.x) slots	6

Weight and Dimensions

Depth	335.3 mm
Width	384 mm
