Super X11DPG-QT User's Manual
New features supported by 2nd Gen Intel Xeon Scalable-SP Series Processors
2nd Generation Intel Xeon Scalable-SP processors support the following features:
• Higher performance for a wider range of workloads with per-core performance increase
• Support of Optane DC Persistent Memory (DCPMM) with a󰀨ordable, persistent, and
large capacity (Refer to Section 1.8 for details.)
• Up to 2933 MHz memory supported
• Vector Neural Network Instruction (VNNI) support for Accelerate Deep Learning & Arti-
cial Intelligence (AI) workloads
• Speed Select Technology provides multiple CPU proles that can be set in the BIOS.
(This feature is available on select CPU SKUs).
• Seamless hardware security mitigations & performance/frequency exibility
Note: Support for 2933MHz memory and DCPMM memory is dependent on the CPU
SKU.
1.3 Special Features
This section describes the health monitoring features of the X11DPG-QT motherboard. The
motherboard has an onboard ASPEED AST2500 Baseboard Management Controller (BMC)
that supports system health monitoring.
Recovery from AC Power Loss
The Basic I/O System (BIOS) provides a setting that determines how the system will respond
when AC power is lost and then restored to the system. You can choose for the system to
remain powered o󰀨 (in which case you must press the power switch to turn it back on), or
for it to automatically return to the power-on state. See the Advanced BIOS Setup section
for this setting. The default setting is Last State.
1.4 System Health Monitoring
This section describes the health monitoring features of the X11DPG-QT motherboard. The
motherboard has an onboard Baseboard Management Controller (BMC) chip that supports
system health monitoring.

Supermicro X11DPG-QT Specifications

General

PS/2 ports quantity	0
IPMI LAN (RJ-45) port	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Number of SATA III connectors	10
Number of DIMM slots	16
Maximum LRDIMM memory	2000 GB
Supported RDIMM module capacity	64GB
Memory voltage	1.2 V
Supported memory types	DDR4-SDRAM
Supported memory clock speeds	2133, 2400, 2666 MHz
BIOS type	AMI
ACPI version	4.0
BIOS memory size	64 Mbit
RAID levels	0, 1, 5, 10
Wi-Fi	No
LAN controller	Intel® X550
Ethernet interface type	10 Gigabit Ethernet
On-board graphics card model	Aspeed AST2500
Bundled software	Intel Node Manager, IPMI2.0, KVM LAN, NMI, SPM, SSM, SUM, SuperDoctor 5, Watchdog
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 90 %
Supported QPI	10.4 GT/s
Processor socket	LGA 3647 (Socket P)
Processor manufacturer	Intel
Processor number of cores supported	28
Component for	Server
Motherboard chipset	Intel® C621
Audio output channels	7.1 channels
PCI Express x16 (Gen 3.x) slots	6

Weight and Dimensions

Depth	335.3 mm
Width	384 mm
