Preface
Preface
About This Manual
This manual is written for system integrators, IT technicians, and knowledgeable end users.
It provides information for the installation and use of the X11DPG-QT motherboard.
About This Motherboard
The X11DPG-QT motherboard supports dual Intel® Xeon® Scalable-SP and 2nd Generation
Intel Xeon Scalable-SP processors (Socket P) with a TDP (Thermal Design Power) of up to
205W and three UPI (Ultra Path Interconnect) links of up to 10.4 GT/s (Note 1 below). With
the Intel C621 chipset built-in, this motherboard supports 3DS LRDIMM/RDIMM/LRDIMM/
NVDIMM DDR4 ECC memory of up to 2933*/2666 MHz in 16 slots (Note 2 below). It also
supports up to 2TB Intel Optane™ DC Persistent Memory in memory mode (2nd Gen Intel
Xeon Scalable-SP 82xx/62xx/52xx/4215 series processors only). The X11DPG-QT provides
maximum performance, system cooling, and PCIe capacity. Also, this motherboard is optimized
for high-performance cloud-computing or high-end graphics server and workstation platforms.
Please note that this motherboard is intended to be installed and serviced by professional
technicians only. For processor/memory updates, please refer to our website at http://www.
supermicro.com/products/.
Notes: 1. UPI/memory speeds are dependent on the processors installed in your sys-
tem. 2. Support for 2933 MHz memory is dependent on the CPU SKU.
Manual organization
Chapter 1 describes the features, specications and performance of the motherboard, and
provides detailed information on the Intel C621 chipset.
Chapter 2 provides hardware installation instructions. Read this chapter when installing the
processor, memory modules, and other hardware components into the system.
Chapter 3 describes troubleshooting procedures for video, memory, and system setup stored
in the CMOS.
Chapter 4 includes an introduction to the BIOS, and provides detailed information on running
the CMOS Setup utility.
Appendix A provides BIOS Error Beep Codes.
Appendix B lists software program installation instructions.
Appendix C lists standardized warning statements in various languages.
Appendix D contains UEFI BIOS Recovery instructions.
Appendix E explains Intel VROC RAID settings.

Supermicro X11DPG-QT Specifications

General

PS/2 ports quantity	0
IPMI LAN (RJ-45) port	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Number of SATA III connectors	10
Number of DIMM slots	16
Maximum LRDIMM memory	2000 GB
Supported RDIMM module capacity	64GB
Memory voltage	1.2 V
Supported memory types	DDR4-SDRAM
Supported memory clock speeds	2133, 2400, 2666 MHz
BIOS type	AMI
ACPI version	4.0
BIOS memory size	64 Mbit
RAID levels	0, 1, 5, 10
Wi-Fi	No
LAN controller	Intel® X550
Ethernet interface type	10 Gigabit Ethernet
On-board graphics card model	Aspeed AST2500
Bundled software	Intel Node Manager, IPMI2.0, KVM LAN, NMI, SPM, SSM, SUM, SuperDoctor 5, Watchdog
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 90 %
Supported QPI	10.4 GT/s
Processor socket	LGA 3647 (Socket P)
Processor manufacturer	Intel
Processor number of cores supported	28
Component for	Server
Motherboard chipset	Intel® C621
Audio output channels	7.1 channels
PCI Express x16 (Gen 3.x) slots	6

Weight and Dimensions

Depth	335.3 mm
Width	384 mm
