Chapter 4: AMI BIOS
4-33
*If the item above "Congure SATA as" is set to RAID, the following
items will display:
Support Aggressive Link Power Management
When this item is set to Enabled, the SATA AHCI controller manages
the power usage of the SATA link. The controller will put the link to
a low power state when the I/O is inactive for an extended period of
time, and the power state will return to normal when the I/O becomes
active. The options are Enabled and Disabled.
Load EFI Driver for RAID
This option enables the system to load the RAID EFI driver during
system boot. Select Enabled to load the EFI driver, select Disabled
to load the legacy driver for system boot.
Serial ATA Port 0~ Port 5
This item displays the information detected on the installed SATA drives
on the particular SATA port.
•Model number of drive and capacity
Port 0 ~ Port 5 Spin Up Device
On an edge detect from 0 to 1, set this item to allow the PCH to start
a COMRESET initialization to the device. The options are Enabled and
Disabled.
Port 0 ~ Port 5 SATA Device Type
Use this item to specify if the SATA port specied by the user should
be connected to a Solid State drive or a Hard Disk Drive. The options
are Hard Disk Drive and Solid State Drive.
