Chapter 4: AMI BIOS
4-37
Detect Non-Compliant Device
Set this option to congure the motherboard to detect any non-
compliant PCIE device installed on any of the PCIE slots. The options
are Enabled and Disabled.
Above 4G Decoding (Available if the system supports 64-bit
PCI decoding)
Select Enabled to decode a PCI device that supports 64-bit in the space
above 4G Address. The options are Enabled and Disabled.
CPU SLOT1 PCI-E 3.0 X8 (IN X16) OPROM,
CPU SLOT2 PCI-E 3.0 X8 (IN X16) OPROM,
PCH SLOT3 PCI-E 2.0 X1 (IN X4) OPROM,
CPU SLOT4 PCI-E 3.0 X8 (IN X16) OPROM,
PCH SLOT5 PCI-E 2.0 X1 (IN X4) OPROM,
CPU SLOT6 PCI-E 3.0 X16 OPROM
Select Disabled to deactivate the selected slot, Legacy to activate the slot
in legacy mode and EFI to activate the slot in EFI mode. The options
are Disabled, Legacy, and EFI.
Onboard LAN Option ROM Type
Select an option to enable Option ROM support to boot the computer
using a network device specied by the user. The options are Disabled,
Legacy and EFI.
Onboard LAN1 Option ROM/Onboard LAN2 Option ROM
Select PXE (Preboot Execution Environment) to boot the computer us-
ing a PXE device installed in a LAN port specied. Select Disabled to
prevent system boot using a device installed in a LAN port. The options
for Onboard LAN1 Option ROM/Onboard LAN2 Option ROM are Disabled
and PXE.
Onboard Video Option ROM (C7X99-OCE-F Only)
Select the type of Video Option ROM support. The options are Disabled,
Legacy and EFI.
VGA Priority
Use this item to select the graphics device to be used as the primary
video display for system boot. The options are Onboard VGA, CPU SLOT1
PCI-E 3.0 X8 (IN X16), CPU SLOT2 PCI-E 3.0 X8 (IN X16), PCH SLOT3
PCI-E 2.0 X1 (IN X4), CPU SLOT4 PCI-E 3.0 X8 (IN X16), PCH SLOT5
PCI-E 2.0 X1 (IN X4), and CPU SLOT6 PCI-E 3.0 X16.
