4-40
Supermicro C7X99-OCE/C7X99-OCE-F Motherboard User’s Manual
•ME Firmware Type - displays the Management Engine rmware type.
•ME Firmware SKU - displays the Management Engine SKU size.
ME FW Image Re-Flash
This item will update the PCH Firmware from an omage in a USB Flash-
drive attached to a USB port. The options are Enabled and Disabled.
Super IO Configuration
Enable Serial Port 1
This item will Enable or Disable Serial Port 1 (COM1). Place a tick mark
on the box to enable Serial Port 1. The default is Enabled.
Current Cong (IRQ)
This item displays the current IRQ setting for Serial Port 1 (COM1).
Change (IRQ) Settings
This item congures the IRQ setting for Serial Port 1 (COM1).
The options for Serial Port 1 are Auto, IO=3F8h; IRQ=4,
IO=3F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12, IO=2F8h; IRQ=3,
4, 5, 6, 7, 9, 10, 11, 12), IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10,
11, 12 and IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12.
