Chapter 1: Introduction
1-3
One (1) Front Panel Audio Header
One (1) SPDIF In/Out on the rear side of the chassis
Super I/O
Nuvoton 6776
BIOS
128 Mb AMI BIOS
®
SPI Flash BIOS
Plug and Play (PnP0, DMI 2.3, PCI 2.3, ACPI
1.0/2.0/3.0, USB Keyboard and SMBIOS 2.7
Power Configuration
ACPI/ACPM Power Management
Main Switch Override Mechanism
Keyboard Wake-up from Soft-Off
Power-on mode for AC power recovery
Health Monitoring CPU Monitoring
Onboard voltage monitors for +1.05V, +5V, +/-
12V, VBAT, Memory, CPU Core
CPU 8-phase switching voltage regulator
CPU/System overheat LED and control
CPU Thermal Trip support
Fan Control
Fan status monitoring with rmware 4-pin fan
speed control
Low noise fan speed control
System Management
PECI (Platform Environment Conguration Inter-
face) 2.0 support
System resource alert via SuperDoctor
®
III
SuperDoctor III, Watch Dog, NMI
IPMI (for X10SRA-F only)
Chassis Intrusion header and detection
CD Utilities
BIOS ash upgrade utility
Drivers and software for Intel® C612 Express
chipset utilities
Other
ROHS 6/6 (Full Compliance, Lead Free)
Dimensions
ATX form factor (12.0" x 9.6") (304.8 mm x
243.84 mm)
