Chapter 2: Installation
2-17
B
A
A.
PS/2
Keyboard/Mouse Port
B.
VGA
Port
VGA Port (X10SRA-F only)
A VGA
port
is located
next
to the
USB
ports
0/1
on
the
I/O
bac
kpanel.
Use
this port to connect to a compatible
VGA
display
.
PS/2
Keyboard/Mouse
Port
A
combination
PS/2
K
eyboard/Mouse
port is supported on the back pa
nel.
This
may
be
used
with
either
a
PS/2
keyboard
or
PS/2
mouse,
or
both
when
using
a
'Y'
PS/2
cable.
46
48
