Chapter 1: Introduction
1-7
Onboard I/O
• Adaptec Ultra 320 AIC-7901 SCSI Controller (*X7SB4 only)
• Intel ICH9R SATA Controller, 6 connectors for 6 devices, supporting RAID
functions 0, 1, 5 and 10 (*RAID 5: supported by Intel's RAID Controller in the
Windows OS environment only.)
• 1 fl oppy port interface (up to 2.88 MB)
• 1 Fast UART 16550 compatible serial port and 1 header
• Intel 82573V and 82573L Gigabit Ethernet Controllers
• PS/2 mouse and PS/2 keyboard ports
• Up to 7 USB ports (1 on-board connector and 2 headers) (*Two additional
USB: USB 7/8 are for OEM only)
• VGA Connector
• SIM 1U IPMI Slot
• Super I/O (Winbond 83627HG), Hardware Monitoring: W83793
• ES1000 w/32MB Video Memory
Temperature
• Monitoring CPU, chassis environment
• CPU Thermal Trip support
• Thermal Monitor 2 (TM2) (available if supported by the CPU)
Other
• Wake-on-LAN (WOL)
• Wake-on-Ring (WOR)
• Onboard +5vsb warning LED Indicator ("LE 1")
• External modem ring-on
CD Utilities
• Drivers and software for Intel 3210 chipset utilities
Dimensions
• 9.6" (W) x 12" (L) (243.84 mmx 304.8 mm)
