Supero X9SRL User Manual

Chapter 1: Introduction
1-7
BIOS 32 Mb SPI AMI BIOS
®
SM Flash BIOS
Play and Plug APM 1.2, DMI 2.3, PCI 2.2, ACPI 1.0/2.0,
USB Keyboard and SMBIOS 2.3
Power Conguration ACPI/ACPM Power Management
Wake On LAN (WOL) Header
Keyboard Wake-up from Soft-Off
CPU Fan Auto-off in Sleep Mode
Power-on mode for AC power recovery
PC Health Monitoring CPU & Chassis Monitoring
Onboard voltage monitors for CPU core, +1.8V, +3.3V,
+5V, +/-12V, +3.3V Stdby, +5V Stdby, VBAT, HT, Memory,
Chipset
CPU 5-phase switching voltage regulator
CPU/System overheat LED and control
CPU Thermal Trip support
CPU & Chassis Environment Monitor
Fan Control
Fanstatusmonitoringwithrmware4-pin(PulseWidth
Modulation) fan speed control
Low noise fan speed control
System Management PECI(PlatformEnvironmentCongurationInterface)2.0
support
System resource alert via SuperDoctor
®
III
Watch Dog, NMI
Intel® Node Manager 2.0 Support
Intel Manageability Engine
Chassis Intrusion header and detection
CD Utilities BIOSashupgradeutility
Drivers and software for Intel® C602 chipset utilities
Other ROHS 6/6 (Full Compliance, Lead Free)
TPM 1.2 on board
DOM (Disk on Module) Power Connector Support
FCC A, EuP Lot 6, WHQL
Dimensions ATX form factor (12.00" x 9.6")
