iii
Preface
Preface
This manual is written for system integrators, PC technicians and
knowledgeable PC users. It provides information for the installation and use of the
X9SRL Motherboard Series.
About This Motherboard
The X9SRL Motherboard Series supports a single Intel® E5-1600 or E5-
2600 2011-pin Socket R series CPU (4 to 8 Cores). With the Intel® C602 chipset
built in, the X9SRL Motherboard Series offers top-of-the-line server performance.
Features such as support for up to 256GB of memory, dual 1Gb LAN, nine (9)
USB ports, six SATA 6Gb/s ports, and an IPMI port (X9SRL-F) make the X9SRL
Motherboard Series ideal for high end rack-mounted single-processor platforms.
Please refer to our website (http://www.supermicro.com/products/) for processor
and memory support updates.
*This product is intended to be installed and serviced by professional technicians.
Manual Organization
Chapter 1describesthefeatures,specicationsandperformanceofthemother-
board, and provides detailed information on the Intel Patsburg chipset.
Chapter 2 provides hardware installation instructions. Read this chapter when in-
stalling the processor, memory modules and other hardware components into the
system. If you encounter any problems, see Chapter 3, which describes trouble-
shooting procedures for video, memory and system setup stored in the CMOS.
Chapter 4 includes an introduction to the BIOS, and provides detailed information
on running the CMOS Setup utility.
Appendix A provides BIOS Error Beep Codes.
Appendix B lists software program installation instructions.
Appendix C contains the UEFI BIOS Recovery instructions.
