Chapter 4: AMI BIOS

4-1

Chapter 4

BIOS

4-1 Introduction

This chapter describes the AMI BIOS Setup Utility for the X9SRL Motherboard

Series. The AMI ROM BIOS is stored in a Flash EEPROM and can be easily up-

dated. This chapter describes the basic navigation of the AMI BIOS Setup Utility

setup screens.

Note: For instructions on BIOS recovery, please refer to the instruction

guide posted at http://www.supermicro.com/support/manuals/.

Starting BIOS Setup Utility

To enter the AMI BIOS Setup Utility screens, press the <Delete> key while the

system is booting up.

Note: In most cases, the <Delete> key is used to invoke the AMI BIOS

setup screen. There are a few cases when other keys are used, such as

<F1>, <F2>, etc.

Each main BIOS menu option is described in this manual. The Main BIOS setup

menu screen has two main frames. The left frame displays all the options that can

be congured. Grayed-out options cannot be congured. Options in blue can be con-

gured by the user. The right frame displays the key legend. Above the key legend

is an area reserved for a informational text. When an option is selected in the left

frame, it is highlighted in white. Often a informational message will accompany it.

(Note: the AMI BIOS has default informational text built in. Supermicro retains the

option to include, omit, or change any of these informational messages.)

The AMI BIOS Setup Utility uses a key-based navigation system called "hot keys".

Most of the AMI BIOS setup utility "hot keys" can be used at any time during the

setup navigation process. These keys include <F1>, <F10>, <Enter>, <ESC>, ar-

row keys, etc.

Note: Options printed in Bold are default settings.

How To Change the Conguration Data

The conguration data that determines the system parameters may be changed by

entering the AMI BIOS Setup utility. This Setup utility can be accessed by pressing

<Del> at the appropriate time during system boot.

Supero X9SRL User Manual
