1-6
X9SRL Motherboard Series User’s Manual
Motherboard Features
CPU Single Intel® E5-1600 and E5-2600 processor in an LGA
2011 pin Socket-R (4~8 Core)
Memory Eight (8) DIMM slots support up to 256GB of DDR3 Unbuf-
fered, ECC RDIMM memory or 64GB of DDR3 Unbuffered,
ECC/non-ECC UDIMM memory, 1066/1333/1600MHz..
Supports dual-channel memory bus
DIMM sizes
UDIMM 1GB, 2GB, 4GB, 8GB, 16GB
RDIMM 2GB, 4GB, 8GB, 16GB, 32GB, 64GB
Chipset Intel® C602
Expansion PCI Slots (using riser cards)
Two (2) PCI-Express 3.0 x8 (in x16 Slot)
Two (2) PCI-Express 3.0 x8 (in x8 Slot)
Two (2) PCI-Express 3.0 x4 (in x8 Slot)
One (1) PCI-Express 2.0 x4 (in x8 Slot)
Network Connections Integrated LAN
Two (2) Intel 82574L Gigabit LAN ports
One (1) IPMI port (X9SRL-F only)
I/O Devices SATA Connections
SATA 2.0 Ports Four (4) via SCU
3 Gb/s RAID 0, 1, 5, 10 (option)
SATA 3.0 Ports Two (2) via PCH
6 Gb/s No RAID
SATA 2.0 Ports Four (4) via PCH
3 Gb/s No RAID
USB Devices
Two (2) USB 2.0 ports on the rear I/O panel
Six (6) USB 2.0 headers for front panel access
One (1) Internal Type A port
Keyboard/Mouse
One (1) PS/2 KB/Mouse combo port on the I/O backpanel
Serial (COM) Ports
Two (2) Fast UART 16550 connection. One on the I/O
back panel (COM1) and one on a header (COM2)
Super I/O
Winbond Super I/O 83527
