14
i
EN
◆ Screwdriver
◆ Scissors
◆ Carpenter's gauge or measuring
tape
◆ Pen
◆ Optionally, a drilling machine
and a 6 mm masonry drill if the
provided hole pattern does not
t or if the belt winder has to be
reinstalled.
6. Safety instructions for the installation
Poor routing of the belt can cause the belt to fail and leads to unnecessary loads
on the belt winder.
◆ Install the belt winder so that the belt runs as straight as possible into the device,
in order to avoid unnecessary friction and wear.
Incorrect installation can lead to property damage.
◆ Strong forces are exerted during operation of the system which require secure
installation on a rm base.
i
6.1 You will require the following tools
