43
i
EN
+ +
16. Removing the ush-mounted belt winder (e.g. in the event of a move)
1.
Erase all settings.
2.
Fully close the roller shutters.
Press and hold the button.
3.
In doing so, pull out the belt as far
as possible from the top of the belt
winder.
4.
Remove the power supply from the
mains socket, open the operating
panel and release the belt from the
fastening hook.
5.
Finally, loosen the two connectors
on the rear of the device with a
small screwdriver and dismantle
the sun sensor.
There is a risk of injury from the
reel.
◆ Never reach into the reel
compartment when the motor
is running. Always remove the
mains plug before touching the
reel compartment.
Pull it out fully and then dismantle the
belt winder.
