1. General view
1. Mounting frame
2. Operating panel
3. Reel compartment
4. Screw cover
5. Disengaging bracket
6. Cable bushings
7. Power supply
connection
8. Sun sensor connection
9. Type plate (incl.
manufacturer details)
1. Wall bracket
2. Operating panel
3. Reel compartment
4. Disengaging bracket
5. Cable bracket
6. Wall bracket front panel
7. Power supply
connection
8. Sun sensor connection
9. Type plate (incl.
manufacturer details)
Surface-mounted model
Flush-mounted model
Key
(see page 5)
