22. Technical Specications
Power supply operating voltage: 230 V / 50 Hz
Standby power: 0.7 W
Nominal power: 24 V DC / 30 W max. 45 W
Torque: MdN = 2.8 Nm
Max. speed: 34 rpm
End tractive force: 7 kg
Max. tractive force / starting tractive force: 25 kg
Transient operation: 5 minutes
Protection class: III
Protection type: IP20 (only for use in dry rooms)
Positioning accuracy: 5 mm
Number of switching times: 2 (UP and DOWN)
Automatic solar function setting range: 2,000 to 20,000 Lux
Ambient temperature: 0 - 40 °C
Sound pressure level (LpA): ≤ 70 dB(A)
Dimensions: see page 51 / 52
Permissible belt widths: 15 mm (Mini belt)
23 mm (belt)
Belt lengths:
15 mm (Minibelt) 5.5 m at 1.0 mm belt thickness
23 mm (Standard belt) 5.5 m at 1.0 mm belt thickness
4.5 m at 1.3 mm belt thickness
