Supmeter BST106-B60S(L) User Manual

18
No.
Sign
Range
Default
Description
Set
131
132
133
134
135
136
137
138
139
140
L1
L2
L3
L4
L5
L6
L7
L8
L9
LA[L10]
1~99999
[*]
1000
2000
3000
4000
5000
6000
7000
8000
9000
10000
Correction Point’s Loading Weight 1~10
Inputted Loading Weight value for Segmenting
Correction.
Demand: L1≤L2≤…≤L10.
Only for query.
141
142
143
144
145
146
147
148
149
150
d1
d2
d3
d4
d5
d6
d7
d8
d9
dA[d10]
-99999~
+99999
[*]
10000
20000
30000
40000
50000
60000
70000
80000
90000
99999
Correction Point’s AD Value 1~10
AD Value detected via Segmenting Correction.
Demand: d1≤d2≤…≤d10.
Only for query.
151
152
153
154
155
156
157
158
159
160
C1
C2
C3
C4
C5
C6
C7
C8
C9
CA[C10]
0.0100~
99.9999
[*]
1.0000
Span Correction Ratio 1~10
Span Correction Ratio of Linearity Segment got by
Segmenting Correction.
 Linearity Segment 1：[Zero Value]~d1.
 Linearity Segment 2：d1~d2.
 Linearity Segment 3：d2~d3.
 …
 Linearity Segment 10：d9~[Max. AD Value].
Max. display value: 9.9999.
Only for query.
161
SC
0~1
0
[*]
Segmenting Weight Calculation Permission
0: oFF
1: on
Operating Authorization: Administrator.
[*]: ‘RAM Reset’ operation has no effect on the parameter.
