Supmeter BST106-B60S(L) - Data Calibration (mV, mA, Voltage)

27
6.3.2.3【V】Data Calibration
Input the specification parameter values of the voltage output type weighing transmitter according to the
actual configuration of the weighing system to correct Span Coefficient. If there is no access to get the
specification parameter values for Data Calibration, then it’s necessary to do Load Calibration.
Prompt Message:
[≡2.5V≡]：【 2.5V】Data Calibration.
[≡5V≡]：【 5V】Data Calibration.
[≡10V≡]：【 10V】Data Calibration.
Main Display Interface
【■】+【►】【 ▲】
【 】+【►】【 ▲】
【 】
M
【 】
Input ‘Total Capacity of Weighing
Transmitter’: 1~99999 Weight Unit.
【 】
【■】: Exit 【 】: Save
M
【 】
Input ‘Zero Value of Weighing
Transmitter’ [E]: 0.000~Max. value [V].
Input ‘Full Value of Weighing
Transmitter’ [F]: 0.000~Max. value [V].
Demand: Full Value > Zero Value.
[105] Span Coefficient value.
【 】
