Supmeter BST106-B60S(L) - Setpoint Parameters (SEtP)

20
No.
Sign
Range
Default
Description
Set
208
AF
0.00~21.00
20.00
Max. AO Value of Weight Signal [mA or V]
It’s the AO current or voltage output value of
weight signal when ‘Weight value ≥[209]’.
209
AC
1~99999
10000
Max. Weight Value for AO Output
210
At
0~1
0
AO Type
0: 20EA [Max. Output 20mA]
1: 10V [Max. Output 10V]
211
dI
0~4
0
DI1 Signal
0: ≡ZEro [Zero Fine Adjustment without
Power-down Protection and without Clearing Tare
Weight]
1: -ZEro [Zero Calibration with Power-down
Protection and Clearing Tare Weight]
2: ≡tArE [Manual Tare without Power-down
Protection]
3: -rStr [Clear Tare Weight with Power-down
Protection]
4: CLS [Clear the display value of Peak Value]
212
AP
1~4
1/2/3/4
[*]
Application Mode
1. HL [Weight Limit DO Alarm Mode]
2. HH [Weight Increment DO Output Mode]
3. LL [Weight Decrement DO Output Mode]
4. SEC [Weight Section DO Output Mode]
Operating Authorization: Administrator.
[*]: ‘RAM Reset’ operation has no effect on the parameter.
