- 11 -
1.4.2.2 Procedure
As below figure
#1
#3
Connecting magnetic valve
to supply water directly
Connecting pump to use circulating
water
Pump outlet
Water quantity cannot
exceed the pump water
level
Connecting pump or magnetic valve power
