- 31 -
> Automatic bevel
The tip vertex position is automatically located 1/3 of the front of the lens.
>33% bevel
The apex of the tip is located about 33 percent above the front of the lens.
> 50% bevel
The apex of the tip is located at 50% of the front surface of the lens.
> Front bevel
The tip vertex position is located on the front surface.
> Back bevel
The apex of the tip is located on the back surface.
IMPORTANT NOTE：
> If the maximum thickness of the lens is less than 2mm, the position of the bevel/slot will be
automatically located at half of the lens.
#7 Select lens fine grinding pattern(bevel)
#9 Select polishing or not；
#10 Select lens processing mode；
#12 After blocking, put the lens in and clamp；
#14 Open the window, remove the shaft and take the lens after
it’s done.
#11 Select clip pressure；
