Switch
NO. 1 force
reducer
NO. 2 force
reducer
NO. 3 force
reducer
Distance
≤1.5m/s 1.5m
2.0m/s>v>1.5m/s 1.5m 3.5m
≥2.0m/s 1.5m 3.5m 5m
S means the setting distance of switch of forced reducer to leveling position. The distance S
must be enough for the deceleration from F3-08 to 0. That means S must suffice following
conditions:
If the distance of forced reducer is too short, the system will alarm failure E45 after lift auto-
tuning .It can be solved through increasing the distance of switch position of forced reducer or
parameter F3-08.
F3-18
Time of starting output with zero
speed
Default 0.200s Min. Unit 0.001s
Setting Range 0.000~1.000s
To protect lift starting ride comfort, the lift control can run with zero speed before brake opening.
At this time, motor is in excitation traveling, and it outputs biggest starting torque.
F3-19
Time-lag of curve running Default
0.200s
(asynchronous)
0.500s(sync)
Min.
Unit
0.001s
Setting Range 0.000~1.000s
This parameter sets time that it takes from the system outputting open signal to the brake
complete opening. It usually needs about 200ms.The system keeps up outputting with zero
speed.
F3-20
Time-lag of end running Default 0.300s Min. Unit 0.001s
Setting Range 0.000~1.000s
It means holding time of zero speed when the curve running ends. Users needn’t modify it.
In running course, the connection of each signal with curve is as follows:
