4-8 FUEL SYSTEM
3. Remove the main air jet 4, the pilot air jet 5 and the screw
6.
4. Remove the pilot jet 7.
5. Remove the bolt 8 and the float chamber 9.
6. Remove the float pin 0, the float A and the float spring B.
Always remove the float pin from the right side to the
left side. (See the figure.)
