Suzuki DF 2.5 - Disassembly

FUEL SYSTEM 4-7
DISASSEMBLY
1. Remove the idle adjusting screw 1.
2. Remove the four screws 2 and plate 3.
 Idle adjusting screw (1)
 Screw (4)
 Plate (1)
 Main air jet (1)
 Pilot air jet (1)
 Screw (1)
 Pilot jet (1)
 Bolt (1)
 Float chamber (1)
 Float pin (1)
 Float (1)
 Float spring (1)
 Needle valve (1)
 Main jet (1)
 Main nozzle (1)
 Gasket (1)
 Screw (1)
 Spring (1)
 Carburetor body (1)
 Float chamber gasket (1)
 Drain screw (1)
 Spring (1)
 Gasket
