5-2 RECOIL STARTER
REMOVAL
1. Remove the motor cover.
2. Tie a knot in the rope inside of the motor cover to prevent the
rope from rewinding onto the recoil reel when the starter grip
is removed.
3. Remove the knot from grip holder 1.
Remove the grip holder 1 and the starter grip 2.
Completely remove the motor cover.
4. Install the starter grip and the grip holder to the end of the
rope.
5. Loosen the knot previously tied in the rope.
6. Remove the recoil starter assy.
To Next Page
