POWER UNIT 6-19
7. Remove the oil pump shaft A, camshaft B and shaft C.
8. Remove the two conrod bolts D and the conrod cap E.
9. Remove the piston with the conrod through the top of the
cylinder bore.
10. Remove the crankshaft F from the cylinder block.
11. Remove the circlips G, the piston pin H, the conrod I and
the piston rings J from the piston K.
