Glass / Windows / Mirrors: 9E-2
Use the specific adhesive which has the following property.
Glass adhesive shearing strength
40 kg/cm
2
(569 lb/in
2
) or more
Adhesive materials and tools required for removal and installation.
• One component urethane adhesive and primers used in combination (For one sheet of windshield).
– Adhesive (470 g (15.7 oz.))
– Primer for glass (30 g (1.0 oz.))
– Primer for body (30 g (1.0 oz.))
– Primer for molding (30 g (1.0 oz.))
• Eyeleteer
• Piano string
• Windshield knife
• Brush for primer application (2 pcs)
•Knife
• Rubber sucker grip
• Sealant gun (for filling adhesive)
• Putty spatula (for correcting adhered parts)
Component Location
Power Window Control System Location
S3RH0A9503001
I3RH0A950001-01
1. Main switch (driver side) 2. Sub switch (passenger side) 3. Sub switch (rear RH and LH)
