Suzuki Liana RH416 Service Manual

7B-75 Air Conditioning System: Automatic Type
Expansion Valve Removal and Installation
S3RH0A7226031
Refer to “Expansion Valve Removal and Installation”.
Expansion Valve Inspection
S3RH0A7226032
Refer to “Expansion Valve Inspection”.
A/C Refrigerant Pressure Switch Removal and
Installation
S3RH0A7226033
Refer to “A/C Refrigerant Pressure Switch Removal and
Installation”.
A/C Refrigerant Pressure Switch Inspection
S3RH0A7226034
Refer to “A/C Refrigerant Pressure Switch Inspection”.
Compressor Relay and Condenser Cooling Fan
Relay Inspection
S3RH0A7226035
Refer to “Compressor Relay and Condenser Cooling
Fan Relay Inspection”.
Compressor Drive Belt Removal and
Installation
S3RH0A7226036
Refer to “Compressor Drive Belt Removal and
Installation”.
Compressor Drive Belt Inspection
S3RH0A7226037
Refer to “Compressor Drive Belt Inspection”.
Compressor Removal and Installation
S3RH0A7226038
Refer to “Compressor Removal and Installation”.
Compressor Inspection
S3RH0A7226039
Refer to “Compressor Inspection”.
Magnet Clutch Components
S3RH0A7226040
Refer to “Magnet Clutch Components”.
Magnet Clutch Removal and Installation
S3RH0A7226041
Refer to “Magnet Clutch Removal and Installation”.
Special Tools and Equipment
Special Tool
S3RH0A7228001
SUZUKI scan tool
—
This kit includes following
items. 1. Tech 2, 2. PCMCIA
card, 3. DLC cable, 4. SAE
16/19 adapter, 5. Cigarette
cable, 6. DLC loop back
adapter, 7. Battery power
cable, 8. RS232 cable, 9.
RS232 adapter, 10. RS232
loop back connector, 11.
Storage case, 12.) / )
