7A-10 Heater and Ventilation:
Scan Tool Data Definitions
TEMP CONT SWITCH: Position of temperature control
selector of HVAC control module
MODE CONT SWITCH: Position of airflow selector of
HVAC control module
FAN CONT SWITCH: Position of air speed selector of
HVAC control module
FAN DESIRE VOLT: Voltage for blower motor
AIR MIX POS SENSOR: Input signal from position
sensor in temperature control actuator
MODE POS SENSOR: Input signal from position
sensor in air flow control actuator
BLOWER FAN LOAD (ON or OFF): ON: Position of
blower speed selector is 1st or 2nd position / OFF:
Position of blower speed selector is more than 3rd
position.
AIR INTAKE MODE (FRE or REC): State of air intake
mode
REC INDICATOR LAMP (ON or OFF): State of
recirculation air (REC) indicator lamp
FRE INDICATOR LAMP (ON or OFF): State of fresh air
indicator lamp
REAR DEF INDICATOR LAMP (ON or OFF): State of
rear defogger indicator lamp
DTC B1511 (No.11): Temperature Control
Actuator (Position Sensor) and/or its Circuit
Malfunction
S3RH0A7104007
Refer to “DTC B1511 (No.11): Temperature Control
Actuator (Position Sensor) and/or its Circuit Malfunction
in Section 7B”.
DTC B1512 (No.12): Air Flow Control Actuator
(Position Sensor) and/or its Circuit malfunction
S3RH0A7104008
Refer to “DTC B1512 (No.12): Air Flow Control Actuator
(Position Sensor) and/or its Circuit malfunction in
Section 7B”.
DTC B1513 (No.13): Temperature Control
Actuator and/or its Circuit malfunction
S3RH0A7104009
Refer to “DTC B1513 (No.13): Temperature Control
Actuator and/or its Circuit malfunction in Section 7B”.
DTC B1514 (No.14): Air Flow Control Actuator
and/or its Circuit malfunction
S3RH0A7104010
Refer to “DTC B1514 (No.14): Air Flow Control Actuator
and/or its Circuit malfunction in Section 7B”.
DTC B1520 (No.20): Temperature Selector and/
or its Circuit malfunction
S3RH0A7104011
Refer to “DTC B1520 (No.20): Temperature Selector
and/or its Circuit malfunction in Section 7B”.
DTC B1521 (No.21): Blower Speed Selector and/
or Its Circuit
S3RH0A7104012
Refer to “DTC B1521 (No.21): Blower Speed Selector
and/or Its Circuit in Section 7B”.
DTC B1522 (No.22): Air Flow Selector and/or its
Circuit Malfunction
S3RH0A7104013
Refer to “DTC B1522 (No.22): Air Flow Selector and/or
its Circuit Malfunction in Section 7B”.
