Suzuki Liana RH416 Service Manual

9E-3 Glass / Windows / Mirrors:
Diagnostic Information and Procedures
Rear Window Defogger Symptom Diagnosis
S3RH0A9504001
Power Window Control System Symptom Diagnosis
S3RH0A9504002
Power Door Mirror Control System (If Equipped) Symptom Diagnosis
S3RH0A9504003
Door Mirror Heater (If Equipped) Symptom Diagnosis
S3RH0A9504004
Condition Possible cause Correction / Reference Item
Rear window defogger
does not operate
Circuit fuse blown Replace fuse and check for short circuit.
Defogger wire faulty Check defogger wire referring to “Rearend
Door Window / Back Window Defogger Wire
Inspection”.
Rear window defogger switch faulty Check rear window defogger switch referring
to “Rearend Door Window / Back Window
Defogger Switch and Its Circuit Inspection”.
Wiring or grounding faulty Repair circuit.
Condition Possible cause Correction / Reference Item
All power windows do not
operate
Circuit fuse blown Replace fuse and check for short circuit.
Ignition switch faulty Check ignition switch referring to “Ignition
Switch Inspection in Section 9C”.
Power window main switch faulty Check power window main switch referring to
“Power Window Main Switch Inspection”.
Wiring or grounding faulty Repair circuit.
Only one power window
does not operate
Wiring and/or coupler faulty Check wiring and/or coupler.
Power window main switch faulty Check power window main switch referring to
“Power Window Main Switch Inspection”.
Power window sub switch faulty Check power window switch sub switch
referring to “Power Window Sub Switch
Inspection”.
Power window regulator faulty Check window regulator.
Wiring or grounding faulty Repair circuit.
Condition Possible cause Correction / Reference Item
All power mirrors do not
operate
Circuit fuse blown Replace fuse and check for short circuit.
Power door mirror switch faulty Check power door mirror switch referring to
“Power Door Mirror Switch Inspection”.
Wiring or grounding faulty Repair circuit.
One power mirror does
not operate
Power door mirror switch faulty Check power door mirror switch referring to
“Power Door Mirror Switch Inspection”.
Power door mirror actuator faulty Check actuator refraining to “Power Door
Mirror Actuator Inspection”.
Wiring or grounding faulty Repair circuit.
Condition Possible cause Correction / Reference Item
The surface of mirror is
mot defrosted although
door mirror heater switch
is ON
Circuit fuse blown Replace fuse and check for short circuit.
Door mirror heater switch faulty Check door mirror heater switch referring to
“Door Mirror Heater Switch (If Equipped)
Inspection”.
Door mirror heater faulty Check door mirror heater referring to “Door
Mirror Heater (If Equipped) Inspection”.
Wiring or grounding faulty Repair circuit.
