SWF SB Series User Manual

55--2299
⑧ Offset Function
This function determines whether to use the automatically designated off-set function or not.
[Fig. 5.4.1-5]
★ Setting Tips to Use Frame Offset Work Function
1. Select “Yes”for the question asking the frame coordinates setting in the basic setting situation.?
2. Go to “Setting”→“Frame Offset Setting”and determine the starting position, the offset middle
position, and the stop position after design completion (offset) (5.4.5 Frame Offset Setting)
3. To use the offset function during embroidery work, go to “Main Function Menu”→“Setting”→
“5.4.5 Frame Offset Setting,”and enter the desired value to “Frame Offset Position”.
※ The above three settings shall be made to carry out the frame offset work.
Embroidery
Starting Point
<Embroidery Begins> <Embroidery Is Finished>
Frame Move
Needle Bar Position After
Embroidery Is Completed
Frame
Frame
