INSTRUCTIONS FOR TROUBLESHOOTING COMMON COMPONENT ERRORS | CARRIER AND SENSOR ERRORS 92
APR/2017 TECHNICAL OPERATIONS AND MAINTENANCE GUIDE | NEXUS STATION
Outgoing carrier not detected at back sensor
See the instructions for troubleshooting the error, “Arriving carrier not detected at back sensor.”
Loosen screws to remove sensor board
DIP switches
FIGURE 9. Troubleshoot Nexus Station load/unload sensor errors
Factory default setting
Set a lower threshold to decrease sensitivity; set a
higher threshold to increase sensitivity of the sensor.
FIGURE 10. DIP-switch settings for the Nexus Station front-load sensor
